Description
Features
- Up to 8 GPM; Up to 5000 PSI
- Honda, Vanguard or Kawasaki Engines
- Belt-Drive Pump with 7-Year Warranty
- 2,000 Watt Generator
- Rugged tri-plunger High-Pressure Pump with forged brass head and 7‑year warranty, is connected to the engine by a belt drive assembly that features cast-iron bushing Pulleys and two notched “V” cogged belts, which provide a cooler operation and longer life.
- Trailer-ready with pre-drilled Trailer Mounting Brackets and pre-plumbed with 3-Way Valve to bypass float tank when drawing water directly from and auxiliary tank. (PHGW5-50524E not trailer ready)
- High-efficiency, Burner is mounted on the end for ease of servicing and adjustments.
- Power Platform is mounted on vibration isolators to extend the life of the key components.
- 2,000 Watt Generator produces reliable power for burner.
- Heavy-duty Fuel-Water Separator has replaceable element for removing water that can damage burner fuel pump.
- Rupture Disk and Thermal Pump Protector protect against excessive heat or pressure.
- Rugged, 11/2-inch square tube Open-Air Frame with Forklift Guides allows easy access and serviceability and is protected by an all-weather resistant Epoxy Powder Coat Finish
- Durable polyurethane Battery Box protects battery and is in easily accessible location.
- Gasoline (5 gallon) and diesel (10 gallons) tanks feature elevated fuel lines to prevent debris in fuel from causing damage. (Gasoline tank is 10 gallons on PGHW5-50524E and 1.5 gallons on PGHW4-30324E)
- EASY!Force trigger gun with cruise control like technology uses its own recoil force to hold the trigger down – so, no more sore hands after hours of use. Variable Pressure Wand make it easy to switch between wash and rinse modes. (PGHW5-50524E has straight-thru wand).
- Rust-free Float Tank with stainless steel inlet filter provides back flow protection and inlet Detergent Injection for applying soap while washing in high pressure mode.
- Industrial-duty Gasoline-Powered Honda or Vanguard engine with overhead valves and easy access oil drain line; all have keyed Electric Start.
- Helpful Tri-Lingual Labels with operating instructions in English, Spanish and French for owner and operator protection.
- Many Safety Features, including a rupture disk, thermal pump protector and high-temperature shut down to guard against any buildup of excessive pressure or heat.
- Conveniently placed Control Panel can be relocated to front of machine and features Adjustable Thermostat to control temperature, and Hour/Tach Meter to indicate engine speed and total operating time.
- Adjustable Detergent Valve for precise high-pressure metering of soap. Optional Steam Valve provides on-demand wet-steam cleaning. (steam valve standard on PGHW5-50524E)
- 50 ft. of 3/9″, double-wire braid Tuff-Skin Hose featuring a 24-inch Hose Guard for burst protection.
- Four Quick-Couple Nozzles are made of hardened stainless steel and are mounted for ready access.
